Ref No.
Part No.
Description
Price (RM)
Enquiry
1
11101QM07000
HEAD ASSY, CYCLINDER
450.00
2
26431QK01000
GEAR, TACHOMETER DRIVEN
12.00
3
09241Q220801
PLUG, HEAD
10.00
4
09206Q080806
PIN 8 x 11
0.70
5
02104Q060355
BOLT M6 X 35
1.20
6
02104Q060605
BOLT M6 X 60
1.20
7
11141QM07010
GASKET, CYLINDER HEAD
35.00
8
09206Q110803
PIN 11 X 16
3.00
10
11151QK01000
RUBBER PAD
1.80
14
09482Q000818
SPARK PLUG (Ref No. 15 In Diagram)
28.00
15
11175QK01000
CAP, INSPECTION (Ref No.16 In Diagram)
9.00
16
09280Q290802
O-RING 3 X 29.5 (Ref No. 17 In Diagram)
4.00
17
09289Q040802
OIL SEAL (Ref No. 18 In Diagram)
4.20
18
09161Q110801
GASKET (Ref No. 19 In Diagram)
3.00
19
26441QK01000
SLEEVE (Ref No. 20 In Diagram)
18.00
20
26451QK01000
O-RING (Ref No. 21 In Diagram)
2.00
21
09128Q050802
SCREW M5 X 12 (Ref No. 22 In Diagram)
0.80
22
09402Q462007
CLAMP (Ref No. 23 In Diagram)
3.50
23
13110QM07000
PIPE, INTAKE (Ref No. 24 In Diagram)
39.00
24
09280Q340802
O-RING 2..4 X 31.7 (Ref No. 25 In Diagram)
3.00
25
03424Q060161
SCREW M6 X 16 (Ref No. 26 In Diagram)
1.40
